■ 产品名称： GB35A

Features

GB35A Series Connector is 0.6mm Height and 0.35m pitch usually
suitable for board to FPCB connection in mobile sets.
The stable contact reliability by dual contact structure and hold down
structure.
I S
upply the High current power contact using hold down structure.
Improve the contact reliability against flux because of V-Notch design.
Improve the Robustness during the mating by plug hold down, be strong
against the damage by external force.
ncrease soldering intensity because of hold down structure.

application

Mobile phone
Compact portable devices, etc
